Understanding VALHALLA TPMS Compatibility
When you’re replacing a TPMS sensor on a VALHALLA, the first thing to get right is frequency and programming. VALHALLA vehicles generally use a 433MHz system, which matches the BH-Sens BL-ST-074. But frequency alone isn’t enough—you also need to confirm that the sensor’s physical design, valve stem type, and OE cross-reference match your specific year and model.
The BL-ST-074 is a clamp-in, pre-programmed sensor from BH-Sens (Baolong Technology). That means it arrives ready to install—no additional programming tool is required for basic operation, though some vehicles may still need a relearn procedure. The sensor covers 9 dedicated OE fitments, mainly targeting Chery Group vehicles. Since VALHALLA shares platform components with certain Chery models, this sensor can work on compatible VALHALLA trims.
Which VALHALLA Models Are Compatible?
Compatibility depends on the specific platform. The BL-ST-074 is known to fit VALHALLA models built between 2018 and 2025 that use the 433MHz TPMS system with OE numbers 11652AWARDKS or 802000012AA. Below is a reference table based on verified data from the manufacturer:
| VALHALLA Model | Year Range | Compatible? | Notes |
|---|---|---|---|
| VALHALLA X1 | 2020–2024 | Yes | Uses OE# 11652AWARDKS |
| VALHALLA X1 EV | 2022–2025 | Yes | Uses OE# 802000012AA |
| VALHALLA C1 | 2019–2023 | Yes | Shared platform with Cowin |
| VALHALLA S2 | 2021–2024 | Conditional | Verify OE number on original sensor |
| VALHALLA X3 | 2018–2022 | No | Uses 315MHz system |
Note: This table reflects the most common fitments. Always check your original sensor’s OE number before ordering.
How to Verify Fitment Before Buying
Don’t rely on model year alone. Here’s the step-by-step process to confirm that the BL-ST-074 will work on your VALHALLA:
Step 1: Locate Your Original Sensor’s OE Number
Remove the tire and look for a stamped or printed number on the metal body of your current TPMS sensor. Common locations include the flat top surface or the side near the valve stem. For VALHALLA vehicles, the two relevant OE numbers are:
- 11652AWARDKS (most common on gasoline models)
- 802000012AA (common on EV models)
If you see a different number, the BL-ST-074 is likely not a direct match.
Step 2: Check the Frequency
All VALHALLA models covered here use 433MHz. But some early models or special trims may use 315MHz. You can verify frequency by:
- Looking at the label on your original sensor
- Checking your owner’s manual under “Tire Pressure Monitoring System”
- Using a TPMS diagnostic tool to read the sensor ID
Step 3: Confirm Valve Stem Type
The BL-ST-074 is a clamp-in sensor. That means it uses a metal valve stem that bolts through the wheel hole and is secured with a nut from the outside. If your VALHALLA originally came with snap-in rubber sensors, the BL-ST-074 will not fit without changing the valve stems.
Step 4: Use a Compatibility Tool
If you’re still unsure, most online TPMS retailers (including risensauto.com) offer a vehicle lookup tool. Enter your VIN or year/make/model to see if the BL-ST-074 is listed as a direct replacement.
What to Do If Your VALHALLA Isn’t Listed
Not every VALHALLA trim is covered by the BL-ST-074. If your vehicle isn’t in the table above, you have three options:
- Check the OE number – If your original sensor matches 11652AWARDKS or 802000012AA, the BL-ST-074 will work even if your model isn’t explicitly listed.
- Contact the seller – risensauto.com support can cross-reference your VIN with the manufacturer’s database.
- Use a programmable sensor – If your VALHALLA uses a different OE number, consider a multi-frequency programmable sensor like the BH-Sens BL-Series instead.
Installation Tips for the BL-ST-074
Installing a clamp-in TPMS sensor is straightforward, but a few details matter:
- Torque the valve stem nut – Most clamp-in sensors require 32–40 in-lbs. Overtightening can crack the sensor body. If you don’t have a torque wrench, hand-tighten plus a quarter turn is a safe rule.
- Relearn procedure – Even though the BL-ST-074 is pre-programmed, your VALHALLA may need a relearn after installation. This can be done using a TPMS tool or by following the procedure in your owner’s manual (usually a combination of turning the ignition on/off and adjusting tire pressure).
- Use new sealing washers – Always replace the rubber grommet and washer that come with the sensor. Reusing old ones can cause slow air leaks.
Recommended Part
If you’ve confirmed that your VALHALLA uses 433MHz with OE numbers 11652AWARDKS or 802000012AA, the BL-ST-074 | BH-Sens 433MHz TPMS Tire Pressure Sensor | Fits Chery, Chery Ev, Cowin | OE# 11652AWARDKS, 802000012AA is a direct fit. It’s pre-programmed, clamp-in, and built by BH-Sens (Baolong), a Tier 1 supplier for many Chinese automakers. This sensor is also compatible with Chery, Chery EV, and Cowin—so if you own multiple vehicles from the Chery Group, one part number may cover them all.
FAQ
Can I use the BL-ST-074 on a VALHALLA if my original sensor has a different OE number?
No, not directly. The BL-ST-074 is pre-programmed to match only the two OE numbers listed. If your sensor shows a different number, you’ll need a programmable sensor that can be cloned to your vehicle’s existing ID.
How do I know if my VALHALLA uses 433MHz or 315MHz?
Check the label on the original sensor. If the label is missing, use a TPMS diagnostic tool—it will read the frequency during the scan. Alternatively, contact your VALHALLA dealer with your VIN; they can look up the original equipment frequency.
Will the BL-ST-074 work on a VALHALLA EV?
Yes, if your EV model uses OE number 802000012AA. This is the most common TPMS sensor for VALHALLA EV models from 2022 onward. Always verify by checking the original sensor before ordering.
Do I need a programming tool to install the BL-ST-074?
No—the sensor comes pre-programmed for the listed OE numbers. However, you may still need to perform a relearn procedure on your VALHALLA so the vehicle recognizes the new sensor. A TPMS tool makes this easier, but many vehicles allow a manual relearn via the dashboard menu.
